CMCP460VT Triaxial 4-20 mA Velocity Sensor

CMCP460VT Triaxial 4-20 mA Velocity Sensor

$
Choose your options:
420VT-X Range(required):
Signal Detection(required):
Captive Mounting Bolt:
Product Code: CMCP460VT
Typical Applications
Fans, Motors, Pumps, Compressors, Centrifuges, Conveyors, Air Handlers, Gearboxes, Rolls, Dryers, Presses, Cooling, HVAC, Spindles, Machine Tooling, Process Equipment and many more.
Features
  • Side Exit, Triaxial Velocity Sensor
  • Three 4-20 mA Outputs (X, Y and Z)
  • Interfaces Directly to Control Systems (PLC’s)
  • 248°F (120°C) Max Temperature Range
  • ISO Standard Frequency Range (10-1.0 kHz)
  • 1 Second Settling Time
  • Stainless Steel Case
  • 8 Pin M12 Eurofast Connector
  • ¼”-28 UNF or M8x1.25 Captive Mounting Bolt
  • Sealed to IP68
Unleash the power of STI Vibration Monitoring's wide array of vibration monitoring equipment, delivering unmatched quality. With a track record of over three decades, we are your go-to source for advanced systems and accessories for predictive maintenance. Our single-channel transmitters and monitors offer precise monitoring of vibration, position, and temperature. Start exploring our affordable integral cables today!
CMCP460VT Data SheetInstallation GuideCMCP422 Manual
