CMCP460VT Triaxial 4-20 mA Output Velocity Sensor CMCP460VT Triaxial 4-20 mA Output Velocity Sensor

  • Side Exit, Triaxial Velocity Sensor
  • Three 4-20 mA Outputs (X, Y and Z)
  • Interfaces Directly to Control Systems (PLC’s)
  • 248°F (120°C) Max Temperature Range
  • ISO Standard Frequency Range (10-1.0 kHz)
  • 1 Second Settling Time
  • Stainless Steel Case
  • 8 Pin M12 Eurofast Connector
  • ¼”-28 UNF or M8x1.25 Captive Mounting Bolt
  • Sealed to IP68
    CMCP460VT Triaxial Velocity

CMCP460AT Triaxial 4-20 mA Output Acceleration Sensor CMCP460AT Triaxial 4-20 mA Output Acceleration Sensor

  • Side Exit, Triaxial Acceleration Sensor
  • Three 4-20 mA Outputs (X, Y and Z)
  • Interfaces Directly to Control Systems (PLC’s)
  • 248°F (120°C) Max Temperature Range
  • Frequency Range (5 Hz -5.0 kHz)
  • 1 Second Settling Time
  • Stainless Steel Case
  • 8 Pin M12 Eurofast Connector
  • ¼”-28 UNF or M8x1.25 Captive Mounting Bolt
  • Sealed to IP68
    CMCP460VT Triaxial Acceleration

Triaxial Sensor, 4-20 mA Output Velocity plus Temperature CMCP460VTT Triaxial 4-20 mA Output Velocity with Temperature Sensor

  • Side Exit, Triaxial Velocity and Temperature Sensor
  • Three 4-20 mA Outputs (X, Y and Z)
  • Temperature Output 10 mV/°C
  • Interfaces Directly to Control Systems (PLC’s)
  • 248°F (120°C) Max Temperature Range
  • ISO Standard Frequency Range (10-1.0 kHz)
  • 1 Second Settling Time
  • Stainless Steel Case
  • 8 Pin M12 Eurofast Connector
  • ¼”-28 UNF or M8x1.25 Captive Mounting Bolt
  • Sealed to IP68
    CMCP460VTT Triaxial Velocity with Temperature
