Side Exit Transmitter with Integral Braided Armored Cable Vibration Analysis Equipment

CMCP422ATS-I Side Exit, Armored Cable

Choose your options:
422 Series Range:
Signal Detection:
Product Code: CMCP422ATS-I
Typical Applications
Fans, Motors, Pumps, Compressors, Centrifuges, Conveyors, Air Handlers, Gearboxes, Rolls, Dryers, Presses, Cooling, HVAC, Spindles, Machine Tooling, Process Equipment and many more.
  • Loop Powered
  • Acceleration Output (Standard 10 Hz to 5.0 kHz)
  • RMS or Peak Detection
  • Side Entry, Integral Armored Cable (IP65)
  • Interfaces Directly to PLC/DCS Systems
  • -13 to +248 °F (-25 to +120 °C) Temperature Range
  • 1/4" x 28 UNF Captive Bolt
The CMCP422ATS-I Series are loop powered 4-20 mA output sensors which are capable of interfacing directly to an analog input card on a PLC or DCS system. The 4-20 mA output is proportional to the full scale range in terms of Acceleration (g's) and are capable of transmitting signals over a long distance without signal loss. The integral cable features a ETFE cable with a stainless steel overbraided armor.

Dive into the world of advanced vibration monitoring equipment with STI Vibration Monitoring. Since 1989, we have set the standard in manufacturing and distributing premium systems and accessories for predictive maintenance. Our commitment to providing economical options is showcased through our single-channel transmitters and monitors for vibration, position, and temperature, offering companies dependable monitoring alternatives. Find your ideal integral cables with us today!
CMCP422ATS-I Data SheetCMCP422S-I DRAWINGCMCP422S-I DXFInstallation GuideCMCP422 Manual
